Old Man Emu suspensions achieve excellence with their range of fully integrated 4x4 shocks & suspension systems.

Vehicle suspension, especially those that are fitted to 4WDs, are complex to say the
least. So many factors go towards determining the right solution that no one "fix" is the answer to all vehicle models.  Old Man Emu is unique. The philosophies, technology & methods behind the development of each of our products combine to ensure you get the best components the world has to offer.

From humble beginnings in the tough world of off road racing in Australia, to now being respected world wide, OME takes a unique approach to the design, development, testing and support of their product range.

Many of their customers love toughing it off road, and this can vary from endless hours, even days, of flat, yet corrugated dirt roads to hardcore, deeply rutted, rock strewn off road tracks. At the other end of the spectrum there are the four wheel drive owners who have no intention of tackling anything remotely off road. Instead, they're looking for dramatically increased ride comfort on the bitumen or to give them access to their weekend property or their favorite, out of the way fishing spot.

2007-2009 FJ Cruisers

Light Load Suspension 2" Lift - $1056.00
For NON-Bullbar/Bumper & Non-Winch Applications
Part# OMEFJCLKS
1 - OME 2884 Front Coil Springs
2 - 90000 Front Nitrocharger Sport Struts
1 - OME 2895 Rear Coil Springs
2 - 60004 Rear Nitrocharger Sport Shocks

Heavy Load Suspension 2" Lift - $1056.00
For Front Bumper & Winch Applications
Part# OMEFJCHKS
1 - OME 2885 Front Coil Springs
2 - 90000 Front Nitrocharger Sport Struts
1 - OME 2895/2896* Rear Coil Springs
2 - 60004 Rear Nitrocharger Sport Shocks

*2896 Coil is designed for rear bumper, extra cargo applications

2010-2015 FJ Cruisers

Light/Medium Load Suspension 2" Lift - $1066.00
For NON-Bullbar/Bumper & Non-Winch Applications
Part# OMEFJC10LKS
1 - OME 2884 Front Coil Springs
2 - 90010 Front Nitrocharger Sport Struts
1 - OME95PF5 Trim Spacer
1 - OME 2895E/2889* Rear Coil Springs
2 - 60080 Rear Nitrocharger Sport Shocks
*2889 Coil is designed for 200-400 lbs of rear load (rear bumper, cargo, etc)

Heavy Load Suspension 2" Lift - $1066.00
For Front Bumper & Winch Applications
Part# OMEFJC10HKS
1 - OME 2885 Front Coil Springs
2 - 90010 Front Nitrocharger Sport Struts
1 - OME95PF5 Trim Spacer
1 - OME 2889/2898* Rear Coil Springs
2 - 60004 Rear Nitrocharger Sport Shocks
*2898 Coil is designed for 400+ lbs of rear load (rear bumper, cargo, etc)

Ultimate Duty BP-51 Suspension Systems:

The new BP-51 range of high performance, bypass shock absorbers is the result of an exhaustive development process aimed at delivering the ultimate in both comfort and control.

Designed, developed and tested entirely in-house by ARB’s team of Old Man Emu ride engineers, BP-51 shock absorbers are vehicle specific and utilise existing mounting locations to provide easy installation without the need for additional vehicle modification.

Unlike most other adjustable shock absorbers, which provide adjustment for compression only, the BP-51 range allows on vehicle, independent adjustability of both rebound and compression to offer class leading ride customisation that can be tailored to individual vehicle or trip requirements.

In addition to the velocity sensitive damping used in most shock absorbers, where the faster the piston moves, the higher the level of damping is generated, BP-51 shock absorbers also generate damping dependent on the position of the piston within the shock absorber’s body via their bypass design.

While most shock absorbers only generate damping based on fluid flowing through the piston, the BP-51 offers an alternative path from one chamber to the other, around the piston in the form of bypass passages. Some fluid flows through the piston and some fluid bypasses around the piston in the bypass passages.

This results in an ability for the shock absorber to provide the best of both worlds, with a comfortable and compliant ride during normal driving and a more controlled ride over more challenging terrain. With greater levels of damping generated at each end of the stroke, the piston slows as it approaches full compression and extension, preventing harsh topping out against the bump stop and allowing larger bumps and corrugations to be absorbed more easily.

2010-2015 FJ Cruisers

Light/Medium Load BP51 Suspension 2" Lift - $3184.00
For NON-Bullbar/Bumper & Non-Winch Applications
Part# OMEFJC10LKBP51
2 - OME BP51 Front Coilover Assemblies
1 - OME 2895E/2889* Rear Coil Springs
2 - OME BP51 Rear Shock Assemblies
*2889 Coil is designed for 200-400 lbs of rear load (rear bumper, cargo, etc)

Heavy Load BP51 Suspension 2" Lift - $3184.00
For Front Bumper & Winch Applications
Part# OMEFJC10HKBP51
2 - OME BP51 Front Coilover Assemblies
1 - OME 2895E/2889* Rear Coil Springs
2 - OME BP51 Rear Shock Assemblies
*2889 Coil is designed for 200-400 lbs of rear load (rear bumper, cargo, etc)

Optional Options/Accessories:

Light Racing Front Upper Control Arms (sold as pair)
Part# SUS25480 - $735.50
(Allows 4 degrees of caster adjustment and 2 degrees of camber adjustment)

Light Racing Heavy Duty Rear Lower Control Arms (sold as pair)
Part# SUS25950 - $282.50

Front Coilover Assembly Service- $75/pair
Available with the purchase of any pair of front OME struts and OME Coils. Price includes new upper strut mounts, washers, retainers and bushings. Assemblies will ship ready for installation on you vehicle, simply remove your old assembly and slide this one into place. Requires far less downtime and additional tools needed to disassemble your existing assemblies when installing an OME system.

Suspension Notes:

• OME95PF5 Trim Spacer recommended to be fitted to the drivers side front strut assembly on 2010-2012 FJ Cruiser models only to prevent lean.
• Trim Spacers may be required to trim vehicle to a maximum of 15mm (9/16") per coil. Spacers must be installed on the top end of coil.
• Old Man Emu Front Coils can only be installed with OME Nitrocharger struts and coil seats.

EMAIL FOR SHIPPING QUOTE
Please include your year and vehicle model as well as your shipping location.

Prices subject to change without notice - Prices updated 12/14/21
